Book Repair: Tipping-In Loose Pages
By Carole Dyal and Pete Merrill-Oldham
Tipping-in is a method for incorporating loose pages -- a detached leaf, replacement page, errata sheet, or other insert -- into a bound volume.
Materials required
Assemble the following: polyvinyl acetate adhesive (PVA) in a low container, wide strips of scrap paper, waxed paper, a bone folder, a glue brush, a pressing board or glass plate, and a weight.
Step 1: Trimming the page and applying adhesive
If the page to be tipped in is larger than the pages of the volume, carefully trim the page to size using a paper cutter. (For replacement pages, try to preserve original margin widths.) Sandwich the page, reverse side up, between two pieces of scrap paper, leaving 1/8-inch visible along the binding edge of the page. The top strip of scrap paper will protect the area that should not be glued. Apply a thin, even layer of PVA to the exposed 1/8-inch edge of the sheet.
Step 2: Positioning the page
Carefully position the insert in place, setting it as far into the gutter as possible while ensuring that the edges are even with the rest of the text block.
Step 3: Securing the page
With the tipped-in sheet squarely in place, and starting in the middle of the page and working out to the top and bottom, slide the tip of a bone folder along the front (unglued) side of the sheet to press it tight.
Step 4: Protecting the text block
Place a sheet of waxed paper into the gutter between the insert and the page before it to protect the text block from excess adhesive.
Step 5: Pressing the volume
Close the book. Place a pressing board or glass plate along the spine edge and set a weight on top. Let stand for several hours.
Conclusions - References
If intervention is prompt, the life of a book can often be extended at very low cost. Unfortunately, damage may progress beyond the point where these basic techniques can be effective. More extensive treatment or commercial library binding may then be warranted. On the following pages are abbreviated lists of sources for conservation information and training.
Further Reading
Collection Conservation Treatment: A Resource Manual for Program Development and Conservation Technician Training. Maralyn Jones, compiler. Berkeley: Conservation Department, The Library, University of California, 1993.
Greenfield, Jane. Books: Their Care and Repair. New York: H.W. Wilson Co., 1983.
Greenfield, Jane. The Care of Fine Books. New York: N. Lyons Books, 1988.
Kyle, Hedi. Library materials preservation manual. Bronxville, NY: Nicholas T. Smith, 1983.
Lavender, Kenneth and Scott Stockton. Book Repair: A How-To-Do-It: A Manual for Librarians. How-To-Do-It Manuals for School and Public Librarians, Number 4. New York: Neal Schuman Publishers, Inc., 1992.
Morrow, Carolyn Clark, and Carole Dyal. Conservation Treatment Procedures: A Manual of Step-by-Step Procedures For the Maintenance and Repair of Library Materials, second edition. Littleton, CO: Libraries Unlimited, 1986. [Out of print.]
Ritzenthaler, Mary Lynn. Preserving Archives and Manuscripts. Chicago: Society of American Archivists, 1993.
Preservation of Library and Archival Materials: A Manual. Sherelyn Ogden, ed. Andover, MA: Northeast Document Conservation Center, 1996.
Preservation Information On Line
Conservation OnLine [CoOL]: http://palimpsest.stanford.edu/
Library of Congress, Preservation Directorate: http://lcweb.loc.gov/preserv/preserve.html
Sources of training
LYRASIS, 1438 West Peachtree Street NW, Suite 200, Atlanta, GA 30309, 800.999.8558 www.lyrasis.org
AMIGOS, 12200 Park Central Drive, Suite 500, Dallas, Texas 75251, 800-843-8482 Fax: 972-991-6061 http://www.amigos.org
To learn more about book repair workshops in your area contact your local bibliographic utility; state library, archives, or historical society; local chapter of the Guild of Book Workers; or regional conservation center.
Locate Professional Conservators:
American Institute for Conservation of Historic and Artistic Works
1717 K Street NW Ste 301 Washington, DC 20006
202-452-9545 fax: 202-452-9328 InfoAic@aol.com
Locate Certified Library Binders:
Library Binding Institute, 7401 Metro Blvd. Suite 325, Edina, MN 55439
612-835-4707 fax: 612-835-4780 71035.3504@compuserve.com
